Quality	Standard	Material No.	Possible Surface Coating:
HC180Y, HC180Y+ZE	DIN EN 10268	1.0922	+ZE according to DIN EN 10152

Testing direction	Yield Point Re (MPa)	Tensil Strength Rm (MPa)	Elongation A80 (in %)	Vertical anisotropy r-value	Solidification exponent n-value
Q	180 – 230	330 – 400	≥ 35	≥ 1,7	≥ 0,19

HC180Y is a cold-rolled micro-alloyed steel in accordance with the DIN EN 10268 standard, which is characterized by its outstanding properties and wide range of applications. It impresses with its high strength, good formability and weldability and therefore offers a reliable and economical solution for demanding applications in a wide range of industries.

Properties

Specified strength for certain loads: With a minimum tensile strength of 180-230 MPa and a minimum elongation at break of 35%, HC180Y offers a strength that allows it to withstand loads. This makes it the ideal choice for use in vehicles, agricultural machinery and commercial vehicles.
Simple and economical processing: The good formability of HC180Y enables simple and economical processing. The steel can be easily bent, drawn and punched, so that even complex geometries can be realized without any problems. This saves time and costs and enables flexible and efficient construction.
Secure and durable connections: HC180Y is characterized by its high weldability. The secure and durable connection of components is therefore possible without any problems, which further expands the range of applications for the material and ensures high reliability and durability of the structures.

Areas of application
HC180Y is used in a wide range of areas, including

Advantages of HC180Y
HC180Y offers outstanding versatility in terms of its applications. Thanks to its wide range of applications, this steel is suitable for a variety of uses. HC180Y is also characterized by its specified strength, which enables it to withstand a wide range of loads. Another advantage is its lower weight compared to similar steels with the same load-bearing capacity. This makes HC180Y an attractive option for applications where weight savings play a role. In addition, HC180Y offers excellent formability, which makes it easy and economical to process. The high weldability of this steel also enables secure and durable connections of components, which further improves its application possibilities.

Processing HC180Y
HC180Y can be processed using all standard cold working methods, such as bending, drawing, punching and welding. Before welding, the surface of the steel should be thoroughly cleaned and degreased.

Summary
HC180Y is a robust and versatile cold-rolled micro-alloyed steel with a unique combination of high strength, good formability and weldability. It is the optimal choice for all applications that require maximum safety and load-bearing capacity and offers a reliable and economical solution for demanding projects.

Cold-rolled micro-alloyed steels are widely used in various industrial applications due to their excellent mechanical properties and versatility. An interesting feature of these steel grades is that they can also be electrolytically galvanized, which further expands their application possibilities. By combining cold-rolled micro-alloyed steel with a zinc coating through the electrolytic galvanizing process, its corrosion resistance is increased. This process makes it possible to manufacture products that offer both high strength and effective protection against corrosion, making them particularly attractive for applications that are exposed to high stress and environmental influences.
The following coatings can also be ordered on one side only, e.g. ZE75/0.

Characteristic overlay factor	Nominal zinc coating per side Thickness µm	Nominal zinc coating per side Mass g/m²	Minimum value per side Thickness µm	Minimum value per page Mass g/m²
ZE25/25	2,5	18	1,7	12
ZE50/50	5,5	36	4,1	29
ZE75/75	7,5	54	6,6	47
ZE100/100	10,0	72	9,1	65

Code letters	Type of surface treatment
P	phosphated
PC	Phosphated and chemically treated
C	chemically passivated
PCO	Phosphated, chemically treated and oiled
CO	Chemically passivated and oiled
PO	Phosphated and oiled
O	oiled
S	sealed
U	galvanized, without surface treatment
